Rated voltage :
220V-240VCable construction :
Twin conductorConductor :
Solid heating coreConductor Insulation :
FluoropolymerCold Lead :
2.5mConnector :
Out spliceCable Diameter :
2.0mmCable Spacing :
80mm or 100mmResistance Tolerance :
+10%/-5%UFH-MAT PRO is safe for both dry and wet environments. and because they're fixed into an adhesive fabric mesh, making heating cable installation quick and easy.
Technical Data:
150w/㎡
| Part NO. | Heat Area | Mat dimensions |
Wattage |
Resistance(Ω) |
| (㎡) | sq.ft | (mxm) | (ft xft) | (150w/㎡) | ||
| UFH-MAT150-1.0 | 1 | 10.80 | 0.5x2 | 1.64x6.56 | 150 | 322.67 |
| UFH-MAT150-1.5 | 1.5 | 16.15 | 0.5x3 | 1.64x9.84 | 225 | 215.11 |
| UFH-MAT150-2.0 | 2 | 21.53 | 0.5x4 | 1.64x13.12 | 300 | 161.33 |
| UFH-MAT150-2.5 | 2.5 | 26.91 | 0.5x5 | 1.64x16.4 | 375 | 129.07 |
| UFH-MAT150-3.0 | 3 | 32.29 | 0.5x6 | 1.64x19.68 | 450 | 107.56 |
| UFH-MAT150-4.0 | 4 | 43.06 | 0.5x8 | 1.64x26.24 | 600 | 80.67 |
| UFH-MAT150-5.0 | 5 | 53.82 | 0.5x10 | 1.64x32.8 | 750 | 64.53 |
| UFH-MAT150-6.0 | 6 | 64.58 | 0.5x12 | 1.64x39.36 | 900 | 53.78 |
| UFH-MAT150-7.0 | 7 | 75.35 | 0.5x14 | 1.64x45.92 | 1050 | 46.1 |
| UFH-MAT150-8.0 | 8 | 86.11 | 0.5x16 | 1.64x52.48 | 1200 | 40.33 |
| UFH-MAT150-9.0 | 9 | 96.88 | 0.5x18 | 1.64x59.04 | 1350 | 35.83 |
| UFH-MAT150-10 | 10 | 107.64 | 0.5x20 | 1.64x65.6 | 1500 | 32.27 |
| UFH-MAT150-12 | 12 | 129.17 | 0.5x24 | 1.64x78.72 | 1800 | 26.89 |
| UFH-MAT150-15 | 15 | 161.46 | 0.5x30 | 1.64x98.4 | 2250 | 21.51 |
UFH- MAT PRO is safe for both dry and wet environments. and because they're fixed into an adhesive fabric mesh, making heating cable installation quick and easy. Also The mat thickness of only 2.0 mm enables underfloor heating installations into most quality two-part adhesive with a minimum increase in floor height.
We can provide customized production services according to your needs. The diameter and material of the cable can be customized according to your requirements.
UTH-cable is a twin-conductor indoor floor heating cable with metal ground wire. It provide a reliable and effective underfloor heating system that can work with tiles and many other floor coverings.
Details
UFH-MAT made up of three different components: fiberglass, heating element, and 2.5-meter standard cold lead.It is suitable for almost floor types, including ceramic tile, stone tile, engineered wood floor, laminate floor etc.
Details
UTH-cable Pro is a twin-conductor floor heating cable with Copper wire braided. It provides a reliable and effective underfloor heating system that can work with tiles and many other floor coverings.
Details
UFH-MAT PRO made up of three different components: fiberglass, heating element, and 2.5-meter standard cold lead.It is suitable for almost floor types, including ceramic tile, stone tile, engineered wood floor, laminate floor etc.
Details
X-cable is a twin-conductor floor heating cable with metal ground wire.It is used for indoor underfloor heating,the subfloor can be ceramic tiles, natural stone and wooden floor etc.
Details
Underfloor Foil-mat is a floor heating system consists of two different components: Inner heating wire and outer aluminum packed cover.
Details
Our Snow Melting Cable IS-Cable is a 7mm outdoor twin conductors’ constant wattage heating cable.It rated at 30w/m and has Fluoroplastic and XLPE double insulation.
Details
Our Snow Melting Mat IS-MAT is a 7mm outdoor twin conductors’ constant wattage heating mat. It rated at 30w/m and has Fluoroplastic and XLPE double insulation.
Details
