Self Regulating Heat Cable SRL-Pro

Self Regulating Heat Cable SRL-Pro can be used for auxiliary heating of solar water heaters. When there is insufficient sunlight or at night, our SRL-Pro can automatically start to provide additional heat to ensure hot water supply.







  • Supply voltage :

    120V / 208-277V
  • Nominal power :

    10W/m ,16W/m , 24W/m , 30W/m , 40W/m
  • Maximum Un-energized temperature :

    85°C
  • Maximum Energized temperature :

    65°C
  • Minimum installation temperature :

    -40°C

Self Regulating Heat Cable SRL-Pro Cable Construction:

1. 0.5m㎡ copper conductors

2. Self-regulating conductive core

3. Thermoplastic insulation

4. Tinned copper braid

5. Fluoroplymer outer jacket(CF)/Thermoplastic outerjacket(CT)



Technical Data:

SRM Series

Output Power@+10°C(W/m)

Max Length@0°C

Max Length@-20°C 16/20A(m)

Size (mm) Weight((kg/km)
10SRL2-CT 10w/m 180 150/180 12.8×6.0 122
10SRL2-CF 10w/m 180 150/180 12.8×6.0 122
16SRL2-CT 16w/m 180 150/180 12.8×6.0 122
16SRL2-CF 16w/m 180 150/180 12.8×6.0 122
24SRL2-CT 24w/m 146 130/146 12.8×6.0 122
24SRL2-CF 24w/m 146 130/146 12.8×6.0 122
30SRL2-CT 30w/m 114/124 88/110 12.8×6.0 122
30SRL2-CF 30w/m 114/124 88/110 12.8×6.0 122
40SRL2-CT 40w/m 84/96 69/84 12.8×6.0 122
40SRL2-CF 40w/m 84/96 69/84 12.8×6.0 122





Self Regulating Heat Cable SRL-Pro Features:

  • Automatic regulation of heat release when the temperature of the heated surface changes
  • Can be cut to desired length
  • Does not overheat and does not burn out when self-intersecting
  • Resistant to precipitation, ultraviolet radiation, temperature changes
  • Can be used in safe and hazardous areas according to IEC 60800 standard
